Tuffpave®
Tuffpave® is an approved thin surface course system (TSCS) produced in accordance with the Specification for Highway Works (SHW) 942. Tuffpave was developed for motorways and other major highways and can be laid by any licensed laying contractor.
Tuffpave uses high quality, high polished stone value (PSV) aggregates and our specially developed polymer modified bitumen (PMB). Tuffpave is tough on noise, skid resistance and wet weather spray with a texture that is retained throughout its service life. Tuffpave is also tough enough to stand up to heavy traffic yet provide an ultra-smooth ride. Tuffpave is laid by licensed contractors who have gone through an approval process with Heidelberg Materials. Tuffpave comes with a 5-year guarantee underwritten by the contractor.
Tuffpave can also be produced using Heidelberg Materials' era 140 warm mix asphalt process, meeting the requirements of current National Highways major network specifications.
Installation
Installation by licensed laying contractor in line with Heidelberg Materials own installation manual in accordance with SHW Clause 942.
Benefits
- 5-year performance guarantee
- Excellent resistance to deformation
- Enhanced ride quality
- Reduced noise
- Excellent spray reduction
- Reduced CO₂ when supplied as era 140
- 100% recyclable
Available with the following options:
era®/CleanAir®/CarbonLock®/AgeLast®/RAP
Applications
- Highways/motorways
- Major projects
- Major local authority networks
Tuffpave technical data
| Coarse aggregate | |
|---|---|
| Layer thickness Details of constituent quality and layer thickness shown below | |
| Surface texture (on installation) | |
| Road and laboratory test results | |
| Los Angeles abrasion value | 30 max |
| Aggregate abrasion value | As specified in SHW Clause 942 (Appendix 7.1) |
| Flakiness index | 20 max (6mm 30max) |
| Nominal sizes | 6mm; 10mm; 14mm |
| Binder | High performance Polymer Modified Bitumen (PMB) |
| 6mm nominal size | 20 – 30mm |
| 10mm nominal size | 25 – 50mm |
| 14mm nominal size | 35 – 50mm |
| 10mm medium texture | 1.1 – 1.6 mm |
| 14mm medium texture | 1.3 – 1.8 mm |
| (All NH Clause 942 Level 3) | |
| Torque bond | Typical figures +800 KPa |
| Noise reduction | NH Clause 942 |
Typical performance figures
| Material property | Test specification | Typical result |
|---|---|---|
| *Design void content | BS EN 12697-6 | ≤ Vmax 5.0% |
| Water sensitivity | BS EN 12697-12 Method A (ITSR) BS EN 12697-23 | ≥ 80% |
| RTPD (wheel tracking) | BS EN 12697-22 Procedure B WTS in Air | ≤ 1.0mm/103 |
*Where specified in appendix 7/1.
Various options are available within the Tuffgrip® and Tuffpave range.
Please see asphalt product matrix for further information or contact technical:
